ME50 Metal Shaft Magnetic Incremental Encoder

Series：

Format：See the following profile

Specifications　　

Encoder model:	ME50 series
name:	ME50 Metal Shaft Magnetic Incremental Encoder
Main specifications:	Dimensions: φ50 X 60mm Operating Voltage: 4.5～5.5VDC Resolution: 100 pulses/360° output signal: A、B、A(一)、B(一
Features：	High quality double ball bearings; Long life with stable signal;
Application field：	Forklift electric steering wheel, etc.

ME50 Product Specification

ONE、MECHANICAL CHARACTERISTIC
1. Starting torque: 1mN.m
2. Inertia torque: 1x10-6/ kg.m2
3. Maximum speed: 6000r/min
4. Shaft loading: 60N Max (radial direction); 40N Max (axial direction)
5. Protection level: IP54

TWO、ELECTRICAL CHARACTERISTIC
1. Working voltage: DC 4.5-5.5V
2. Input current: 30 mA Max
3. Total current: ＜50mA

4. Output signal: A、B、A(一)、B(一

5. Output voltage: VOH＞0.7VDD, VOL＜0.5V
6. Pulses: 100 pulses

7. Respond frequency: 10MHz

Note: In this catalog, if some parameters or drawings are different from the "Approval sheet", it's subject to the "Approval sheet".

download ME50.pdf
